FTTH Fiber Optic Tools 3 Wavelengths 1310 1490 1550nm Compact PON Power Meter

Ask Lasest Price
Brand Name :	DAMU
Model Number :	PON METER
Price :	$70-90/PCS
Payment Terms :	L/C, T/T, Western Union, MoneyGram
Supply Ability :	1000PCS per day
Delivery Time :	3-5days

Add to Cart

Product Details
Company Profile

FTTH Fiber Optic Tools 3 Wavelengths 1310 1490 1550nm Compact PON Power Meter

Suitable FTTH PON OPM Network 3 wavelengths 1310 1490 1550nm compact Pon Power Meter

PON Optical Power Meter

Optical Pon Power Meter Fiber Test Tools

* Themeter test threshold can be set through the management
software
* Automaticshutdown (can be cancelled)
* Userscan test 1490 in the PON network at the same time nm,
1550nm, 1310nm three wavelengths
* Simultaneouslymeasure and display diﬀerent PON architectures,
data and video signals
* Theinstrument provides ﬁve sets of thresholds to choose from,
with pass, warning, and fail modes
* Manualcalibration

FTTH Fiber Optic Tools 3 Wavelengths 1310 1490 1550nm Compact PON Power Meter

Model	PON
Measuring wavelength	1310nm	1490nm	1550nm
Sensor Type	InGaAS
Linearity	±0.2dB@1550nm≥-40dBm
Isolation With ﬁltering function	1490nm Wavelength＞40dB	1310nm Wavelength＞40dB	1310nm Wavelength＞40dB
	1550nm Wavelength＞40dB	1550nm Wavelength＞30dB	1490nm Wavelength＞30dB
Testing range	-40dBm～+16dBm	-50dBm～+16dBm	-50dBm～+23dBm
Insertion loss in penetration mode (dB)	Less than 1.5dB
Measurable optical frequency broadband	1260～1360	1480～1500	1539～1565
Inherent uncertainty	0.5dB±1nW@1550nm
Display resolution	0.01dB
Threshold setting	5 groups are set by the host computer
Calibration wavelength	1310nm/1490nm/1550nm
Data storage	900 groups
Operating temperature	-10℃～+50℃
Relative humidity	0%～95%RH
Interface type	SC/UPC(Other types can be customized)
Power supply	3 AA batteries

FTTH Fiber Optic Tools 3 Wavelengths 1310 1490 1550nm Compact PON Power Meter
