FC/SC/LC/ST UPC Polish Singlemode Fiber Optical Jumper 3m Yellow
Fiber Optical Patch Cord
Fiber Optic Patch Cable is also known as fiber optic jumper or fiber optic patch cord. It
is composed of a fiber optic cable terminated with different
connectors on the ends. Fiber optic patch cables are used in two
major application areas: computer work station to outlet and patch
panels or optical cross connect distribution center. TTI fiber provides various types of fiber optic patch cables including
single-mode, multimode, multi-core, armored patch cables, as well
as fiber optic pigtails and other special patch cables. For most of
the patch cables, the SC, ST, FC, LC, MU, MTRJ,connectors (APC/UPC
polish) are all available. In addition, we also have MTP/MPO cables in stock.
Description
Cable Color: Yellow
Fiber counts: 1 Fiber (Simplex)
Fiber type: Singlemode (9/125um)
Connector type: ST-SC
Connector counts: 2 connectors
Application
¨ Telecommunication
¨ CATV, FTTH, LAN
¨ Fiber oiptic sensors
¨ Optical transmission system
¨ Test equipment
Features
¨ Screw-thread coupling mechanism
¨ Ceramic ferrules connectors
¨ Low insertion loss, high return loss
¨ Excellent mechanical endurance
¨ High credibility and stability
¨ Good in repeatability and exchangeability
¨ 100% Insertion, Return Loss, End Face and Interference inspection
Specification
Parameter |
Unit |
FC, SC, LC |
ST, MU |
MTRJ, MPO |
SM |
MM |
SM |
MM |
SM |
MM |
PC |
UPC |
APC |
PC |
PC |
UPC |
PC |
PC |
UPC |
PC |
Insertion Loss |
dB |
≤0.3 |
≤0.2 |
≤0.3 |
≤0.2 |
≤0.3 |
≤0.2 |
≤0.2 |
≤0.3 |
≤0.2 |
≤0.2 |
Return Loss |
dB |
≥45 |
≥50 |
≥60 |
≥30 |
≥45 |
≥50 |
≥30 |
≥45 |
≥50 |
≥35 |
Repeatability |
dB |
≤0.1 |
Durability |
dB |
≤0.2dB typical change, 1000 matings |
Operating temperature |
ºC |
-20 ~ +75 |
Storage temperature |
ºC |
-40 ~ +85 |
Feature
• Low insertion loss,high return loss
• Excellent Temperature stability
• Good repeatability and exchangeability
• Excellent mechanical endurance
• Strict curing time and temperature control
• Strict testing standards and methods for quality
• Environment protection (ROHS Compliance)
• The fiber optical patch cord can be customized according to
customers'specific
requirements (Customized Connector/Length/package...)
• 100% NEW raw material and well quality control ensure the best
life time.
1.Can we get a free sample firstly?
Yes,free sample for test is available to each customer.
2.Are you a trader or manufacturer?
We are the leader manufacturer in the filed of RF components since
1992.
3.What is your MOQ?
No MOQ for any sample test,at least 10pcs after sample order.
4.OEM/ODM Service is available?
Yes,the production base of CNCR has the strong ability to offer
OEM/ODM service.
5. What's your company advantage?
We have our own R&D, production, sell and the rich experience
technical support center.
We specialize in offering whole network solution and all equipments
needed in this solution.
6. Please let us know more details about Trade Terms, payment and
leadtime.
Payment Terms:T/T 100% in advance,Paypal and Western Union for the
sample order
Price Terms:FOB Shanghai/Ningbo
Internal Express: EMS,DHL,Fedex,TNT,UPS,by sea or your own shipping
agent
Leadtime: Sample order,1-3work days; mass production 7-15 work days
after the deposit
7.How about the Warranty?
The first year: replace the new equipment if the your products
failed
The second and third year: supplying free maintanence service, just
charge components cost fee and labor fee.
