2 Way Fiber Optic Splitter 1*2 Sc Upc Plc Splitter G657A1 Cable For Terminal Box

    Buy cheap 2 Way Fiber Optic Splitter 1*2 Sc Upc Plc Splitter G657A1 Cable For Terminal Box from wholesalers

    Buy cheap 2 Way Fiber Optic Splitter 1*2 Sc Upc Plc Splitter G657A1 Cable For Terminal Box from wholesalers
    • Buy cheap 2 Way Fiber Optic Splitter 1*2 Sc Upc Plc Splitter G657A1 Cable For Terminal Box from wholesalers
    • Buy cheap 2 Way Fiber Optic Splitter 1*2 Sc Upc Plc Splitter G657A1 Cable For Terminal Box from wholesalers
    • Buy cheap 2 Way Fiber Optic Splitter 1*2 Sc Upc Plc Splitter G657A1 Cable For Terminal Box from wholesalers
    • Buy cheap 2 Way Fiber Optic Splitter 1*2 Sc Upc Plc Splitter G657A1 Cable For Terminal Box from wholesalers

    2 Way Fiber Optic Splitter 1*2 Sc Upc Plc Splitter G657A1 Cable For Terminal Box

    Ask Lasest Price
    Brand Name : DAMU
    Model Number : DM-PS-1*2SCUPC
    Certification : CE ROSH ISO9001
    Payment Terms : T/T
    Supply Ability : 300000pcs/month
    Delivery Time : 5-8
    • Product Details
    • Company Profile

    2 Way Fiber Optic Splitter 1*2 Sc Upc Plc Splitter G657A1 Cable For Terminal Box

    Product Details
    Connector TypeSC,FC,LC,STFerrule End-facePC, UPC,APC
    Fiber TypeG652D G657AFiber ModeSM MM
    PackageSteel Tube, ABS Black BoxStructure1*2/1*4/1*8/1*16/1*32/1*64
    High Light

    fiber optic coupler

    ,

    fiber optic plc splitter

    Specification:


    Table 1 – 1×N PLC Splitter

    Parameters1×21×41×81×161×321×64
    Operating Wavelength (nm)1260～1650
    Fiber TypeG657A or customer specified
    Insertion Loss (dB)(P/S Grade)3.8/4.07.1/7.310.2/10.513.5/13.716.5/16.920.5/21.0
    Loss Uniformity (dB)0.40.60.81.21.52.0
    Return Loss (dB) (P/S Grade)55/5055/5055/5055/5055/5055/50
    Polarization Dependent Loss(dB)0.20.20.20.250.30.35
    Directivity (dB)555555555555
    Wavelength Dependent Loss(dB)0.30.30.30.50.50.5
    Temperature Stability(-40～85 ℃)(dB)0.40.40.40.50.50.5
    Operating Temperature (℃)-40～85
    Storage Temperature (℃)-40～85
    PackageSteel Tube or ABS

    Table 2 – 2×N PLC Splitter

    Parameters2×22×42×82×162×322×64
    Operating Wavelength (nm)1260～1650
    Fiber TypeG657A or customer specified
    Insertion Loss (dB)4.07.611.014.417.521.0
    Loss Uniformity (dB)0.61.01.21.51.82.2
    Return Loss (dB) (P/S Grade)55/5055/5055/5055/5055/5055/50
    Polarization Dependent Loss(dB)0.20.20.30.30.40.4
    Directivity (dB)555555555555
    Wavelength Dependent Loss(dB)0.30.40.50.50.50.5
    Temperature Stability(-40～85 ℃)(dB)0.40.40.40.50.50.5
    Operating Temperature (℃)-40～85
    Storage Temperature (℃)-40～85
    PackageSteel Tube or ABS

    Notes:

    1. Specified without connectors.
    2. Add an additional 0.15dB loss per connector
    3. Product Description

      8 Way Optical Splitter Fiber Optic 1*8 Sc Upc Plc Splitter 0.9mm G657A1 Cable For Terminal Box


      Description:


      Fiber Splitter is one of the most important passive devices in the optical fiber link.

      PLC Splitter is optical fiber tandem device with many input terminals and many output terminals, Especially applicable to a passive optical network (EPON, GPON, BPON, FTTX, FTTH etc.) to connect the MDF and the terminal equipment and to achieve the branching of the optical signal.


      Feature:


      Good high temperature low temperature performance

      Convenient engineering applications

      Fine polarization

      Wide scope wavelength

      Tight and fine structure
      Excellent parameters on IL & RL

      High reliability and directivity

      Non-sensitive wavelength


      Application:


      CATV network
      LAN, WAN and MAN
      Testing equipments

      Fiber optic communication system
      FTTX access network based on PON structure
      Local loop and passive optical network (PON)

    Product Picture:

    2 Way Fiber Optic Splitter 1*2 Sc Upc Plc Splitter G657A1 Cable For Terminal Box2 Way Fiber Optic Splitter 1*2 Sc Upc Plc Splitter G657A1 Cable For Terminal Box2 Way Fiber Optic Splitter 1*2 Sc Upc Plc Splitter G657A1 Cable For Terminal Box

    FAQ

    1.who are we?
    We are based in Guangdong, China, start from 2018,sell to Eastern Europe(18.00%),Western Europe(13.00%),Northern
    Europe(11.00%),South Asia(10.00%),North America(9.00%),Mid East(8.00%),Central America(7.00%),South America(7.00%),Eastern
    Asia(6.60%),Africa(5.00%),Domestic Market(2.20%),Southern Europe(1.20%),Oceania(1.00%),Southeast Asia(1.00%). There are total
    about 11-50 people in our office.

    2.how can we guarantee quality?
    Always a pre-production sample before mass production;
    Always final Inspection before shipment;

    3.what can you buy from us?
    fiber optic polishing machine,fast connector,fiber optic polishing jig,fiber optic patch cord

    4.why should you buy from us not from other suppliers?
    12 years of experience advanced level in optical fiber equipment, we have OEM and ODM capabilities. We have always been in the
    leading position in the same industry with superb workmanship, excellent quality, good pre-sales and after-sales services.

    5.what services can we provide?
    Accepted Delivery Terms: FOB,EXW；
    Accepted Payment Currency:USD,EUR,CNY;
    Accepted Payment Type: T/T,Credit Card,PayPal,Western Union;
    Language Spoken:English,Chinese
